Coseismic Deformation and Fault Slip Distribution of the 2023 Morocco Mw 6.8 Earthquake Observed by InSAR
-
摘要: 2023年9月9日在摩洛哥高阿特拉斯山脉发生MW 6.8地震，造成约
3000 人死亡，5000 多人受伤。该区域处于阿尔卑斯-喜马拉雅地震带，是一个地壳变形活跃的区域，长期受到板块碰撞和断层活动的影响。为了研究此次地震的同震变形特征与机制，本文基于InSAR技术处理升降轨SAR资料，并开展了模型反演研究。InSAR同震形变场结果显示，此次地震以垂向变形为主，是一次典型的逆冲型地震，视线向地表最大相对位移约为15～20 cm；同震位错反演结果显示，断层滑动主要集中在15～35 km深度范围，最大滑动量为1.13 m，且集中在约23 km深度处。累积地震矩为2.2×1019 N·m，矩震级为6.8级。本文研究揭示了此次地震同震变形与断层滑动分布，丰富了缓慢变形山区的强震震例，为地震破坏正演模型提供了基础，并为研究巨大灾害损失成因提供了支持。Abstract: On September 9, 2023,The MW 6.8 earthquake occurred in the High Altas Mountains of Morocco. Approximately3000 people were killed and more than5000 others were injured. This area is locatedin the Alpine-Himalayan belt and is a region with active crustal deformation, having been long influenced by plate collisions and fault activities. In view of the coseismic deformation characteristics and mechanism of the earthquake, this paper utilizes InSAR technology to process ascending and descending SAR data, and carried out model inversion research. The principal results include: (1) InSAR coseismic deformation field show that this earthquake is mainly characterized by vertical deformation resulting from a typical thrust rupture, and the maximum relative displacement of the line of sight of InSAR on the surface is about 15 – 20 cm; (2) Coseismic dislocations show that fault slip is mainly concentrated in the depth range of 15 – 35 km, with a maximum value of 1.13 m and the maximum slip concentrated at a depth of 23 km. Meanwhile, the cumulative seismic moment is 2.2×1019 Nm. The moment magnitude is 6.8. Through this study, on the one hand, the co-seismic deformation and fault slip distribution of this earthquake are revealed, which enricates the examples of strong earthquakes in the slowly deformed mountainous area; on the other hand, the research results can provide a model basis for the forward modeling of earthquake damage and provide support for the research on the causes of huge disaster losses.1)1 2https://www.cenc.ac.cn/earthquake-manage-publish-web/designated-catalogue 2)2 3https://earthquake.usgs.gov/earthquakes/eventpage/us7000kufc/finite-fault 3)3 https://earthquake.usgs.gov/earthquakes/eventpage/us7000 kufc/finite-fault -
图 1 摩洛哥地震构造背景和InSAR观测数据分布
Figure 1. Seismic tectonic background and InSAR observation data distribution in study region. The red beach ball represents the focal mechanism of the 2023 MW 6.8 Moroccan earthquake
图 2 2023年摩洛哥地震InSAR干涉相位、同震形变场和形变剖面
Figure 2. InSAR interferometric phase, coseismic deformation field, and deformation profile of the 2023 Moroccan earthquake
图 3 InSAR观测形变场、模拟形变场与残差分布图
Figure 3. InSAR observation, simulation and residual coseismic distribution field
图 4 2023年摩洛哥MW 6.8地震同震滑动分布[4]
Figure 4. The 2 D and 3 D coseismic slip distribution of the MW 6.8 earthquake in Morocco in 2023
表 1 InSAR干涉影像数据信息
Table 1. InSAR interferometric image data information
卫星 轨道号 飞行方向 波长/cm 主影像 辅影像 空间基线/m 时间基线/d Sentinel-1A T45 升轨 5.6 20230822 20230915 20 12 T52 降轨 5.6 20230904 20230916 28 12 T154 降轨 5.6 20230830 20230911 47 12
下载: 导出CSV
表 2 2023摩洛哥MW 6.8地震震源机制解
Table 2. Source mechanism solution of the 2023 Morocco MW 6.8 earthquake
震中 节面信息 信息来源 纬度/°N 西经/°E 震源深度/km 震级/MW 走向/° 倾角/° 滑动角/° 美国地质调查局 31.058 171.615 19.0 6.8 251 69 69 中国地震局台网中心 31.00 171.45 10.0 6.9 128 25 136 260 73 72
下载: 导出CSV
表 3 断层模型模拟形变场残差
Table 3. Fault model simulation of residual deformation field
轨道号 残差均值/cm 标准差/cm 均方根误差/cm 升轨（T45） −0.09 1.29 1.29 降轨（T52） −0.50 0.90 1.03 降轨（T154） 0.83 0.98 1.29
下载: 导出CSV
-
陈运泰, 林邦慧, 王新华等, 1979. 用大地测量资料反演的1976年唐山地震的位错模式. 地球物理学报, 22(3): 201−217.Chen Y. T., Lin B. H., Wang X. H., et al., 1979. A dislocation model of the Tangshan (唐山) earthquake of 1976 from the inversion of geodetic data. Acta Geophysica Sinica, 22(3): 201−217. (in Chinese) 冯万鹏, 许力生, 李振洪, 2010. 2008年10月当雄MW6.3级地震断层参数的InSAR反演及其构造意义. 地球物理学报, 53(5): 1134−1142.Feng W. P., Xu L. S., Li Z. H., 2010. Fault parameters of the October 2008 Damxung MW6.3 earthquake from InSAR inversion and its tectonic implication. Chinese Journal of Geophysics, 53(5): 1134−1142. (in Chinese) 韩光洁, 孙丽, 杨志高, 2023. 利用反投影技术快速测定中强震矩震级及破裂过程−−以2023年9月9日摩洛哥MW6.9地震为例. 中国地震, 39(3): 680−688.Han G. J., Sun L., Yang Z. G., 2023. Rapid estimation of the moment magnitude and rupture process of moderate and large earthquakes using back-projection−a case of Morocco MW6.9 earthquake on September 9, 2023. Earthquake Research in China, 39(3): 680−688. (in Chinese) 李宁, 赵强, 孙赫, 2018. 2015年塔吉克斯坦MS7.4地震的InSAR观测及其构造意义. 大地测量与地球动力学, 38(1): 43−47, 110. doi: 10.14075/j.jgg.2018.01.010Li N., Zhao Q., Sun H., 2018. InSAR observation results of the 2015 Tajikistan MS7.4 earthquake and its tectonic significance. Journal of Geodesy and Geodynamics, 38(1): 43−47,110. (in Chinese) doi: 10.14075/j.jgg.2018.01.010 李媛, 刘峡, 刘希康等, 2016. 2016年门源MS6.4地震前祁连山周边断层活动分析. 大地测量与地球动力学, 36(4): 288−293. doi: 10.14075/j.jgg.2016.04.002Li Y., Liu X., Li X. K., et al., 2016. Activity analysis of faults around Qilianshan before the 2016 Menyuan MS6.4 earthquake. Journal of Geodesy and Geodynamics, 36(4): 288−293. (in Chinese) doi: 10.14075/j.jgg.2016.04.002 乔学军, 游新兆, 杨少敏等, 2009. 当雄MS6.6地震的InSAR观测及断层位错反演. 大地测量与地球动力学, 29(6): 1−7. doi: 10.14075/j.jgg.2009.06.014Qiao X. J., You X. Z., Yang S. M., et al., 2009. Study on dislocation inversion of MS6.6 Damxung earthquake as constrained by InSAR measurement. Journal of Geodesy and Geodynamics, 29(6): 1−7. (in Chinese) doi: 10.14075/j.jgg.2009.06.014 单新建, 马瑾, 王长林等, 2002. 利用星载D-INSAR技术获取的地表形变场提取玛尼地震震源断层参数. 中国科学(D辑), 32(10): 837−844.Shan X. J., Ma J., Wang C. L., et al., 2004. Co-seismic ground deformation and source parameters of Mani M7.9 earthquake inferred from spaceborne D-InSAR observation data. Science in China Series D: Earth Sciences, 47(6): 481−488. (in Chinese) 单新建, 宋小刚, 韩宇飞等, 2009. 汶川MS8.0地震前InSAR垂直形变场变化特征研究. 地球物理学报, 52(11): 2739−2745.Shan X. J., Song X. G., Han Y. F., et al., 2009. The characteristics of surface vertical deformation before the Wenchuan MS8.0 earthquake from InSAR. Chinese Journal of Geophysics, 52(11): 2739−2745. (in Chinese) 单新建, 屈春燕, 龚文瑜等, 2017. 2017年8月8日四川九寨沟7.0级地震InSAR同震形变场及断层滑动分布反演. 地球物理学报, 60(12): 4527−4536.Shan X. J., Qu C. Y., Gong W. Y., et al., 2017. Coseismic deformation field of the Jiuzhaigou MS7.0 earthquake from Sentinel-1A InSAR data and fault slip inversion. Chinese Journal of Geophysics, 60(12): 4527−4536. (in Chinese) 谭凯, 沈强, 乔学军等, 2010. 汶川MW7.9地震InSAR同震形变场的校检. 大地测量与地球动力学, 30(2): 14−18, 24. doi: 10.3969/j.issn.1671-5942.2010.02.004Tan K., Shen Q., Qiao X. J., et al., 2010. Test of InSAR coseismic deformations field of Wenchuan MW7.9 earthquake. Journal of Geodesy and Geodynamics, 30(2): 14−18,24. (in Chinese) doi: 10.3969/j.issn.1671-5942.2010.02.004 王守文, 季灵运, 朱良玉等, 2022. 基于InSAR技术监测2021年青海玛多MW7.4级地震同震形变场与断层滑动. 地球科学与环境学报, 44(6): 1016−1026.Wang S. W., Ji L. Y., Zhu L. Y., et al., 2022. Co-seismic deformation field and fault slip distribution of the 2021 Maduo MW7.4 earthquake in Qinghai, China based on InSAR technology. Journal of Earth Sciences and Environment, 44(6): 1016−1026. (in Chinese) 王卫民, 郝金来, 姚振兴, 2013. 2013年4月20日四川芦山地震震源破裂过程反演初步结果. 地球物理学报, 56(4): 1412−1417.Wang W. M., Hao J. L., Yao Z. X., 2013. Preliminary result for rupture process of Apr. 20, 2013, Lushan earthquake, Sichuan, China. Chinese Journal of Geophysics, 56(4): 1412−1417. (in Chinese) 王永哲, 陈石, 陈鲲, 2021. InSAR数据约束的2020年西藏定日MW5.7地震源模型及构造意义. 地震, 41(1): 116−128. doi: 10.12196/j.issn.1000-3274.2021.01.009Wang Y. Z., Chen S., Chen K., 2021. Source model and tectonic implications of the 2020 Dingri MW5.7 earthquake constrained by InSAR data. Earthquake, 41(1): 116−128. (in Chinese) doi: 10.12196/j.issn.1000-3274.2021.01.009 温扬茂, 何平, 许才军等, 2012. 联合Envisat和ALOS卫星影像确定L'Aquila地震震源机制. 地球物理学报, 55(1): 53−65. doi: 10.6038/j.issn.0001-5733.2012.01.006Wen Y. M., He P., Xu C. J., et al., 2012. Source parameters of the 2009 L'Aquila earthquake, Italy from Envisat and ALOS satellite SAR images. Chinese Journal of Geophysics, 55(1): 53−65. (in Chinese) doi: 10.6038/j.issn.0001-5733.2012.01.006 张广伟, 雷建设, 梁姗姗等, 2014. 2014年8月3日云南鲁甸MS6.5级地震序列重定位与震源机制研究. 地球物理学报, 57(9): 3018−3027.Zhang G. W., Lei J. S., Liang S. S., et al., 2014. Relocations and focal mechanism solutions of the 3 August 2014 Ludian, Yunnan MS6.5 earthquake sequence. Chinese Journal of Geophysics, 57(9): 3018−3027. (in Chinese) 周健, 2023. 摩洛哥地震科学研究简介与6.9级地震灾情分析. 城市与减灾, (6): 59−66.Cheloni D., Famiglietti A. N., Tolomei C., et al., 2024. The 8 September 2023, MW 6.8, Morocco earthquake: a deep transpressive faulting along the active high atlas mountain belt. Geophysical Research Letters, 51(2): e2023GL106992. (in Chinese) Chen C. W. , 2001. Statistical-cost network-flow approaches to two-dimensional phase unwrapping for radar interferometry. California: Stanford University. Delcaillau B., Amrhar M., Namous M., et al., 2011. Transpressional tectonics in the Marrakech High Atlas: insight by the geomorphic evolution of drainage basins. Geomorphology, 134(3-4): 344−362. doi: 10.1016/j.geomorph.2011.07.010 Huang K. , Wei G. G. , Chen K. J. , et al. , 2024. The 2023 MW 6.8 Morocco earthquake: a lower crust event triggered by mantle upwelling? Geophysical Research Letters, 51(12): e2024GL109052 Kanamori H., Rivera L., 2008. Source inversion of W phase: speeding up seismic tsunami warning. Geophysical Journal International, 175(1): 222−238. doi: 10.1111/j.1365-246X.2008.03887.x Moudnib L. E., Timoulali Y., Nouayti A., et al., 2023. Seismotectonic model of High-Middle Atlas Junction (Morocco) derived from earthquake focal mechanism and stress tensor analysis. Modeling Earth Systems and Environment, 9(2): 2407−2423. doi: 10.1007/s40808-022-01630-0 Okada Y., 1992. Internal deformation due to shear and tensile faults in a half-space. Bulletin of the Seismological Society of America, 82(2): 1018−1040. doi: 10.1785/BSSA0820021018 Oussou A., Ouarhache D., Boumir K., et al., 2024. Identification and characterisation of seismites in the continental Jurassic red beds: implications for synsedimentary tectonics in the central High Atlas (Morocco). Journal of Iberian Geology, 50(2): 193−223. doi: 10.1007/s41513-024-00229-x Qu C. Y., Zhang G. H., Shan X. J., et al., 2013. Coseismic deformation derived from analyses of C and L band SAR data and fault slip inversion of the Yushu MS7.1 earthquake, China in 2010. Tectonophysics, 584: 119−128. doi: 10.1016/j.tecto.2012.05.011 Sandwell D. , Mellors R. , Tong X. P. , et al. , 2011. Open radar interferometry software for mapping surface Deformation. Eos, Transactions American Geophysical Union, 92(28): 234. Wang H. , Ge L. L. , Xu C. J. , et al. , 2007. 3-D coseismic displacement field of the 2005 Kashmir earthquake inferred from satellite radar imagery. Earth, Planets and Space, 59(5): 343−349. Wang R. , Motagh M. , Walter T. R. , 2008. Inversion of slip distribution from co-seismic deformation data by a sensitivity - based iterative fitting method. In: EGU General Assembly 2008. Vienna: EGU. Wu Y. Q., Jiang Z. S., Liang H. B., et al., 2016. Coseismic deformations of the 2015 MW 7.8 Gorkha earthquake and interseismic strain accumulation in the Himalayan tectonic belt and Tibetan Plateau. Tectonophysics, 670: 144−154. doi: 10.1016/j.tecto.2015.12.028 Xu X. H., Sandwell D. T., Tymofyeyeva E., et al., 2017. Tectonic and anthropogenic deformation at the Cerro Prieto geothermal step-over revealed by sentinel-1A InSAR. IEEE Transactions on Geoscience and Remote Sensing, 55(9): 5284−5292. doi: 10.1109/TGRS.2017.2704593 Yeck W. L., Hatem A. E., Goldberg D. E., et al., 2023. Rapid source characterization of the 2023 MW6.8 Al Haouz, Morocco, earthquake. The Seismic Record, 3(4): 357−366. doi: 10.1785/0320230040 -
